5536 TW hose couplings
TW hose couplingWith serrated tail for hose clamp assembly and male thread |
|
| Norm thread | DIN EN ISO 228-1 |
| Thread description | BSPP thread / G-thread |
| Material | Brass |
| Working pressure | 16 bar |
Description
| Art.-no. | For hose Ø inner mm | Male thread | Weight |
|---|---|---|---|
| 5536025025 | 25 | 1″ | 0,190 kg |
| 5536032032 | 32 | 1.1/4″ | 0,210 kg |
| 5536038038 | 38 | 1.1/2″ | 0,290 kg |
| 5536050050 | 50 | 2″ | 0,388 kg |
| 5536075075 | 75 | 3″ | 0,957 kg |
| 5536100100 | 100 | 4″ | 1,600 kg |
