5605 Safe-lock Kamlok female type C
Safe-Lock KamlokFemale coupler with smooth hose tail type C, suitable for safety clamp assembly including two handles with safety locking system to prevent unwanted disconnection of the coupling. Frequently used in critical applications in chemistry and petrochemistry to increase safety of employees and the environment.
|
|
| Norm | EN 14420-7 (vormals DIN 2828) |
| Material | Stainless steel (1.4408) |
| Working pressure | 16 bar |
| Material seal/gasket | NBR |
| Colour sealing | Black |
| Material safety clip | Stainless steel (1.4301) |
| Material lever | Stainless steel (1.4408) |
| Quantity handles | 2 |
| Material ring | Stainless steel (1.4301) |
| Drawing |  |
Description
| Art.-no. | Nominal size | Weight |
|---|---|---|
| 5605019000 | 3/4″ | 0,300 kg |
| 5605025000 | 1″ | 0,400 kg |
| 5606032000 | 1.1/4″ | 0,560 kg |
| 5605038000 | 1.1/2″ | 0,570 kg |
| 5605050000 | 2″ | 0,720 kg |
| 5605063000 | 2.1/2″ | 0,980 kg |
| 5605075000 | 3″ | 1,300 kg |
| 5605100000 | 4″ | 1,600 kg |
